Drester Dynamic Triple

A unique patented and closed system of handling solvent.
Consists of a recycler and a docking unit that is connected to any Drester solvent or combo gun cleaner. The recycler can be used as a stand-alone product

sustainable spraygun cleaning from drester

Dynamic Triple consists of a recycler and a docking unit that is connected to any Drester solvent or combo gun cleaner.

Drester 120 - Recycler - can be used as a stand-alone product, connected to Ace solvent or combo gun cleaner.
Drester RDX - Docking unit - needs to be connected to Drester 120 and Ace solvent or combo gun cleaner.

Cost savings

Reduce the solvent consumption to save money and the environment

Time saving

Keep the spray guns cleaner and speed up the workflow

Safe and clean

The dirty and hazardous manual solvent handling is eliminated and keeps the workshop clean

Technical Specification

Drester RDX - Docking unit
Part.no. RDX2 (for all Drester Ace S/C, not inside DI2C/DG2C)
Shipment dimensions
Drester RDX - Docking unit
Part.no. RDX-8012 (Drester Classic 2600, 3600 & 8000, DC 11 & 12)
Shipment dimensions
1 pcs on 1/2 pallet, 600*800 mm, 40 kg
Drester 120 - Recycler
Part.no. DR-120-A
Shipment dimensions
1 pcs on ½ pallet, 600*800 mm, 97 kg

Drester RDX (Docking unit, needs to be connected to Drester 120 and Ace solvent or combo gun cleaner.)

Weight
21 kg (46 lbs)
Height
700 mm (17,5”)
Diameter
500 mm (19,5”)
Compressed air needed
Clean, dry air at 3-10 bar
Solvent capacity
Max. 80 liters
Pump capacity
10 l/minutes
Liquid pressure
2 bar

Drester 120 (Recycler - can be used as a stand-alone product, connected to a solvent or combo gun cleaner.)

Weight
67 kg (148 lbs)
Width
590 mm (23”)
Height
1610 mm (63”)
Max depth
120 mm (47”)
Type of solvents distillable
Thinner type
Boiler capacity
12 litres
Residues discharge
Plastic bag
Condensation system
By air
Condensate material
Stainless steel
Time/cycle
3-4 hours
Voltage
200-240 V single Phase 50 or 60Hz
Electrical construction
Explosion proof

Manual

Drester 120 Recycler, user manual
PDF
1.41 MB
Download
Drester Dynamic Triple (RDX 9012) - user manual
PDF
261.8 KB
Download
Drester Dynamic Triple (RDX 9012) - assembly manual
PDF
1.32 MB
Download
Drester Dynamic Triple (RDX 8012) - user manual
PDF
684.51 KB
Download
Drester Dynamic Triple (RDX 8012) - assembly manual
PDF
1.6 MB
Download
Drester RDX - installation kit for 44S, 42S
PDF
1.59 MB
Download
Drester RDX - installation guide 22C
PDF
689.18 KB
Download
