IRT Infrared Booster

Infrared booster for surface coating contractor

The Challenge

In powder coating lines, parts often lose temperature between the primer gel stage and the top coat station. This leads to inconsistent results and limits production efficiency.

The Solution

IRT Booster restores and stabilizes the required temperature—ensuring consistent process conditions and enabling higher throughput.

Maintains optimal part temperature between process steps
Supports both small and large components
Integrates seamlessly into overhead conveyor systems
Adapts automatically to varying part dimensions

IRT Infrared Booster

Product information

IRT Booster restores and stabilizes the required temperature—ensuring consistent process conditions and enabling higher throughput.

Maintains optimal part temperature between process steps
Supports both small and large components
Integrates seamlessly into overhead conveyor systems
Adapts automatically to varying part dimensions

Key Benefits

Increase line efficiency

Boost temperature exactly where needed and keep your production flow running at optimal speed.

Flexible for varying parts

Sensors detect width and height of components, activating only the required heating zones.

Precise process control

Individually adjustable zones (0–100%) allow tailored heating profiles for different products.

Compact and easy to integrate

Small footprint and adjustable height enable retrofitting into existing powder coating lines.

How It Works

The system is positioned along the conveyor between process stages.

Sensors detect part dimensions
Heating zones activate accordingly
Power is adjusted per zone via HMI
Predefined “recipes” ensure repeatable results

This ensures efficient and controlled temperature boosting without overheating or energy waste.

Typical Application

Powder coating lines

Between primer gel and top coat stations
Overhead conveyor systems
Mixed product sizes and geometries

System Configuration (Example)

80 kW system with control cabinet
2 PowerCassettes (one on each side)
10 infrared lamps per side (4 kW each)
Individually controlled heating zones
Sensor-based automatic adjustment

Result

Required temperature increase achieved
Improved flexibility for different product types
Eliminated production bottlenecks
Increased overall line efficiency

IRT Infrared Booster

Video

IRT Infrared Booster

Specifications

Type of Heater	Booster - Infrared
Heating Process	Powder curing
Type of Industry	Surface Coating Contractor
Client Process	Overhead conveyor
How to implement	Stand-alone Fixed
What material to heat	Parts - Metal

IRT Infrared Booster

Product documents

Document name	Document ID	Document type	Language
Infrared Booster 303500	303500	Brochure	EN	Download

Show all documents

Document name	Document ID	Document type	Language

No documents found.

IRT Infrared Booster

Product images
